Hot rolled sheets
Check out our broad offer of metallurgical products.
Structural steel sheets
Structural steel sheets rolled in accordance with the PN-EN 10025-2:2004 standard for general use in machine engineering and construction.
|
Grade of steel |
Remin. MPa |
Rm MPa |
Elongation A5 min. % |
KV min. |
CEVmax. for nominal thickness in mm |
|||||
|
|
|
|
|
oC |
J |
≤40 |
>40 ≤150 |
>150 ≤250 |
||
| S235JR | 235 | 360-510 | 24 | 20 | 27 | 0,35 | - | - | ||
| S235J0 | 235 | 360-510 | 24 | 0 | 27 | 0,35 | 0,38 | 0,40 | ||
| S235J2 | 235 | 360-510 | 24 | -20 | 27 | 0,35 | 0,38 | 0,40 | ||
| S355JR | 355 | 470-630 | 20 | 20 | 27 | 0,45 | 0,47 | 0,49 | ||
| S355J0 | 355 | 470-630 | 20 | 0 | 27 | 0,45 | 0,47 | 0,49 | ||
| S355J2 | 355 | 470-630 | 20 | -20 | 27 | 0,45 | 0,47 | 0,49 | ||
| S355K2 | 355 | 470-630 | 20 | -20 | 40 | 0,45 | 0,47 | 0,49 | ||
S235JR+N grade
Gatunek S235JR+N
Gatunek S355J2+N
